O KSM32ED8/32HC da Kingston é um módulo de memória
DDR4-3200 de 4G x 72 bits (32GB) CL22 SDRAM (DRAM síncrona), 2Rx8, ECC, com
base em dezoito componentes FBGA 2G x 8 bits. O SPD é programado para
latência padrão JEDEC DDR4-3200 tempo de 22-22-22 a 1.2V. Cada DIMM de 288
pinos utiliza contatos de ouro.
::Especificações técnicas
Marca: Kingston
Modelo: KSM32ED8/32HC
- CL (IDD): 22 ciclos
- Tempo de ciclo de linha (tRCmin): 45,75ns (min.)
- Tempo de comando de refresh (tRFCmin): 350ns (min.)
- Tempo de linha ativa (tRASmin): 32ns (min.)
- Classificação UL: 94 V-0
- Temperatura de operação: 0ºC a +85ºC
- Temperatura de armazenamento: -55ºC a +100ºC.
Recursos
- Fonte de alimentação: VDD = 1,2 V típica
- VDDQ = 1,2 V típico
- VPP = 2,5 V típico
- VDDSPD = 2,2 V a 3,6 V
- Terminação nominal e dinâmica na matriz (ODT) para dados, strobe e sinais
de máscara
- Auto-atualização de baixa potência (LPASR)
- Inversão de barramento de dados (DBI) para barramento de dados
- Geração e calibração de VREFDQ na matriz
- Dual-rank
- EEPROM de detecção de presença serial I2 on-board (SPD)
- Sensor de temperatura com SPD integrado
- 16 bancos internos; 4 grupos de 4 bancos cada
- Corte de burst fixo (BC) de 4 e comprimento de burst (BL) de 8 através do
conjunto de registro de modo (MRS)
- Selecionável BC4 ou BL8 on-the-fly (OTF)
- Topologia fly-by
- Comando de controle terminado e barramento de endereço
- PCB: Altura 1,23 ”(31,25 mm)
- Compatível com RoHS e livre de halogênio
Placas Compativeis
Acer
- Altos BrainSphere P130 F7
- Altos BrainSphere P15 F7
- Altos P130 F8
- Veriton K8-680G / VK8-680G
ASRock
- DeskMeet X300 Series
- IMB-X1313 Motherboard
- IMB-X1314 Motherboard
- IMB-X1711 Motherboard
- IMB-X1712 Motherboard
- Server 1U-Open19-g3.tiny.x86
- Server 1U-Open19-m3.small.x86
- Server 1U1G-C256/2L2T
- Server 1U1G-X570/2L2T
- Server 1U2E-C252
- Server 1U2E-X570
- Server 1U2LW-X470
- Server 1U2LW-X570
- Server 1U2LW-X570/2L2T
- Server 1U2N2G-B550
- Server 1U2N2G-C252/2T
- Server 1U4LW-C252
- Server 1U4LW-X470
- Server 1U4LW-X470 RPSU
- Server 1U4LW-X570
- Server 1U4LW-X570 RPSU
- Server 1U4LW-X570/2L2T
- Server 1U4LW-X570/2L2T RPSU
- Server 4U18N-B550
- Server 4U18N-B550/2T
- Server 4U18N-C252
- Server 4U18N-C252/2T
- Server Board B450D4U-V1L
- Server Board B550D4-4L
- Server Board B550D4ID-2L2T
- Server Board B550D4M
- Server Board B550D4U
- Server Board B550D4U-2T
- Server Board E3C252D4ID-2T
- Server Board E3C252D4U
- Server Board E3C252D4U-2T
- Server Board E3C256D2I
- Server Board E3C256D4ID-2T
- Server Board E3C256D4ID-NL
- Server Board E3C256D4ID2
- Server Board E3C256D4U-2L2T
- Server Board E3C256D4U-2L2T/BCM
- Server Board X570D4U
- Server Board X570D4U-2L2T
- Server Board X570D4U-2L2T/BCM
- TRX40 Creator Motherboard
- TRX40 Taichi Motherboard
- TRX40D8-2N2T Motherboard
- W480 Creator Motherboard
- W480D4U Motherboard
- W480M WS Motherboard
- WRX80 Creator / WRX80 Creator R2.0 Motherboard
ASUS
- P12R-E Motherboard
- P12R-E/10G-2T Motherboard
- P12R-I Motherboard
- P12R-M Motherboard
- P12R-M-10G-2T Motherboard
- PRIME B550M-K/CSM
- PRIME TRX40-Pro
- PRIME TRX40-Pro S
- Pro E500 G6 Workstation
- Pro E500 G7 Workstation
- Pro WS W480-ACE Motherboard
- Pro WS WRX80E-SAGE SE WIFI
- Pro WS WRX80E-SAGE SE WIFI II
- ROG Strix TRX40-E Gaming
- ROG Strix TRX40-XE Gaming
- ROG Zenith II Extreme
- ROG Zenith II Extreme Alpha
- RS100-E11-PI2 Server
- RS300-E11-PS4 Server
- RS300-E11-RS4 Server
- TS Server TS100-E11-PI4
- WS720T Workstation
- WS750T Workstation
Fujitsu
- CELSIUS J5010 (D3828)
- CELSIUS J5012
- CELSIUS W5011
- PRIMERGY RX1330 M5 (D3929)
- PRIMERGY TX1310 M5 (D3931) LFF
- PRIMERGY TX1320 M5 (D3931)
- PRIMERGY TX1330 M5 (D3931)
Gigabyte
- C246-WU4 Motherboard
- C246M-WU4 Motherboard
- G182-C20 Server (MC22-HS1)
- MC12-LE0 Motherboard
- MC62-G40 Motherboard
- MC62-G41 Motherboard
- MW34-SP0 Motherboard
- MX33-BS0 Motherboard
- TRX40 AORUS MASTER Motherboard
- TRX40 AORUS PRO WIFI Motherboard
- TRX40 AORUS XTREME Motherboard
- TRX40 Designare Motherboard
- W331-Z00 Workstation
- W480 VISION D Motherboard
- W480 VISION W Motherboard
- W480M VISION W Motherboard
- W771-Z00 Workstation (MC62-G40)
- Z390 GAMING X Motherboard
MSI
- Creator TRX40 Motherboard
- D3030a/D3030b Motherboard
- Server System S1101
- TRX40 PRO 10G Motherboard
- TRX40 PRO WIFI Motherboard
QNAP
- NAS Servers TS-1655
- NAS Servers TS-855X
- NAS Servers TS-873AU-RP
- NAS Servers TS-h1887XU-RP
- NAS Servers TS-h2287XU-RP
- NAS Servers TS-h3087XU-RP
- NAS Servers TS-h3088XU-RP
- NAS Servers TS-h987XU-RP
- NAS Servers TVS-h1288X
- NAS Servers TVS-h1688X
Supermicro
- A3SSV-16C-SPLN10F Motherboard
- A3SSV-24C-SPLN10F Motherboard
- A3SSV-8C-SPLN10F Motherboard
- IoT SuperServer SYS-110A-16C-RN10SP (Super A3SSV-16C-SPLN10F)
- IoT SuperServer SYS-110A-24C-RN10SP (Super A3SSV-24C-SPLN10F)
- Super Workstation SYS-530A-IL (Super X12SAE)
- SuperServer / SuperWorkstation SYS-530T-I
- SuperServer SYS-110C-FHN4T (Super X12SCZ-TLN4F)
- SuperServer SYS-110T-M (Super X12STH-SYS)
- SuperServer SYS-510T-M (Super X12STH-SYS)
- SuperServer SYS-510T-ML (Super X12STL-F)
- SuperServer SYS-510T-MR (Super X12STH-SYS)
- SuperServer SYS-510T-WTR (Super X12STW-TF)
- SuperServer SYS-530MT-H8TNR (Super X12STD-F)
- X12SAE Motherboard
- X12SAE-5 Motherboard
- X12SCA-5F Motherboard
- X12SCA-F Motherboard
- X12SCZ-F Motherboard
- X12SCZ-TLN4F Motherboard
- X12STD-F Motherboard
- X12STE-F Motherboard
- X12STH-F Motherboard
- X12STH-LN4F Motherboard
- X12STH-SYS Motherboard
- X12STL-F Motherboard
- X12STL-IF Motherboard
- X12STW-F Motherboard
- X12STW-TF Motherboard
Tyan Computers
- S8020 Motherboard
- Tempest CX S5560 Series
- Tempest EX S5565 Series
Peso c/ Embalagem: 0,4 Kg |
|
| Disponibilidade: Sem estoque no momento | |
| EAN: 0740617325287 | |
| Modelo (GTIN): KSM32ED8/32HC | |
| Categoria: Memória para Desktop | |
| Código: 34189 | |
---
